Metal Framing System
–– Featuring the Unique Weldless Connection

The Metal Framing System incorporates the innovative product improvements that our R&D group has created to give you the most complete and flexible support system available.

Click on the for more information about the system.

Time and moneysaving solution alternative to conventional support method with great Advantage with features:

  • No Welding
  • No Drilling
  • 100% Adjustable
  • 100% Reusable

Metal Framing Accessory Parts:

Note: Click to view the metal channel framing system overview...

Hex-head bolt threads easily into a spring nut, connecting fitting to channel in one quick one-hand operation.

Nut teeth create a vise-like grip, tying sides together in a strong “box” configuration, when the nut is tightened against the in-turned edges.

Spring allows precision placement anywhere along channel length, then holds the nut in position while connection is completed

Channel edges and the nut's tapered grooves act as guides to provide fool-proof alignment of connection.

Chamfer in the nut eases starting of the bolt. Nut teeth create a strong, vise-like grip when tightened against the inturned channel edges.
